COUGAR SX550/R power supply unit

COUGAR SX550/R power supply unit

542 W 20+4 pin ATX ATX Black, Orange, Silver

Model SX550/RPart no. COUGAR SX550/R

44 specifications
  • ColourBlack, Orange, Silver
  • Total power542 W
  • Motherboard power connector20+4 pin ATX
  • PurposePC
  • Width150 mm
  • Sustainability certificatesENERGY STAR
See all specifications

Overview

Colour
Black, Orange, Silver
Total power
542 W
Motherboard power connector
20+4 pin ATX
Purpose
PC
Width
150 mm
Sustainability certificates
ENERGY STAR
Brand
COUGAR
Model
SX550/R
Part number
COUGAR SX550/R
Also known as
COUGAR SX550/R power supply unit 542 W 20+4 pin ATX ATX Black, Orange, Silver

Specifications

44 specifications in 8 groups

Power

Total power542 W
Peak power550 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current5 - 10 A
Maximum input current (@110V)+12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V
Power Factor Correction (PFC) typeActive
Max output current (+3.3V)25 A
Max output current (+12V1)20 A
Max output current (+12V2)20 A
Max output current (+12V3)24 A
Max output current (+12V4)24 A
Max output current (+5V)25 A
Max output current (-12V)0.6 A
Max output current (+5Vsb)3 A
Efficiency91%
Power protection featuresOver current, Over voltage, Overload, Short circuit, Under voltage, Overheating

Ports & interfaces

Motherboard power connector20+4 pin ATX
Number of SATA power connectors7
Peripheral (Molex) power connectors (4-pin)5
EPS power connector (8-pin)Yes
PCI Express power connectors (6-pin)3
PCI Express power connectors (6+2 pin)1
CPU power connector (4+4 pin)Yes
ATX power connector (20+4 pin)Yes
Floppy drive power connector1
CPU power connectors (8-pin)1
Cabling typeSemi-Modular
Monitor outletNo

Performance

PurposePC
Power supply unit (PSU) form factorATX
80 PLUS certification80 PLUS Silver

Design

Product colourBlack, Orange, Silver
Cooling typeActive
Fan diameter14 cm
Number of fans1 fan(s)
Fan locationSide

Certificates

CertificationCB, CE, FCC

Weight & dimensions

Width150 mm
Depth180 mm
Height86 mm

Technical details

Sustainability certificatesENERGY STAR

Other features

Dimensions (WxDxH)150 x 180 x 86 mm
Maximum current25 A
