COUGAR SX550 power supply unit
550 W Black, Orange, White
Model SX550Part no. SX 550EAN 4710918402860
26 specifications
- ColourBlack, Orange, White
- Total power550 W
- Number of SATA power connectors7
- PurposePC
- Width150 mm
Overview
- Colour
- Black, Orange, White
- Total power
- 550 W
- Number of SATA power connectors
- 7
- Purpose
- PC
- Width
- 150 mm
- Brand
- COUGAR
- Category
- Power Supply Unit
- Model
- SX550
- Part number
- SX 550
- EAN / UPC
- 4710918402860
- Also known as
- COUGAR SX550 power supply unit 550 W Black, Orange, White
Specifications
26 specifications in 5 groups
Power
| Specification | Value |
|---|---|
| Total power | 550 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 10 A |
| Combined power (+3.3V) | 140 W |
| Combined power (+12V) | 542 W |
| Combined power (+5V) | 140 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V2) | 20 A |
| Max output current (+12V3) | 24 A |
| Max output current (+12V4) | 24 A |
| Max output current (+5V) | 25 A |
| Max output current (-12V) | 0.6 A |
| Max output current (+5Vsb) | 3 A |
Ports & interfaces
| Specification | Value |
|---|---|
| Number of SATA power connectors | 7 |
| Peripheral (Molex) power connectors (4-pin) | 5 |
| PCI Express power connectors (6-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 1 |
| CPU P4 connector (4-pin) | 20 |
| Floppy drive power connector | 1 |
| Cabling type | Semi-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Orange, White |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 180 mm |
| Height | 86 mm |
