COUGAR GX800 power supply unit

COUGAR GX800 power supply unit

800 W 24-pin ATX ATX Black

Model GX800Part no. COUGAR GX 800EAN 4710918407209

41 specifications
  • ColourBlack
  • Total power800 W
  • Motherboard power connector24-pin ATX
  • PurposePC
  • SafetyCB,CE, FCC, CCC
  • Sustainability certificatesENERGY STAR
See all specifications

Overview

Colour
Black
Total power
800 W
Motherboard power connector
24-pin ATX
Purpose
PC
Safety
CB,CE, FCC, CCC
Sustainability certificates
ENERGY STAR
Brand
COUGAR
Model
GX800
Part numbers
COUGAR GX 800, COUGAR GX800V3/R, 31TG080.0060
EAN / UPC
4710918407209
Also known as
COUGAR GX800 power supply unit 800 W 24-pin ATX ATX Black

Specifications

41 specifications in 8 groups

Power

Total power800 W
AC input voltage115 - 240 V
AC input frequency50 - 60 Hz
Input current10 A
Maximum input current (@110V)+12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V
Combined power (+3.3V)75 W
Combined power (+12V)792 W
Combined power (+5V)75 W
Max output current (+3.3V)25 A
Max output current (+12V)92 A
Max output current (+5V)25 A
Max output current (-12V)0.5 A
Max output current (+5Vsb)3.5 A
Efficiency93%
Power protection featuresOver current, Over voltage, Overload, Short circuit, Under voltage, Overheating

Ports & interfaces

Motherboard power connector24-pin ATX
Number of SATA power connectors10
Peripheral (Molex) power connectors (4-pin)6
PCI Express power connectors (6+2 pin)4
CPU power connector (4+4 pin)Yes
Floppy drive power connector1
Connector(s)IEC C14
Cabling typeSemi-Modular

Performance

PurposePC
Power supply unit (PSU) form factorATX
80 PLUS certification80 PLUS Gold
Bearing technologyFDB

Design

Product colourBlack
Fan diameter14 cm
Number of fans1 fan(s)
Fan speed1800
Fan locationTop
LED indicatorsNo

Safety regulation & standards

SafetyCB,CE, FCC, CCC

Certificates

Certification2009/125/EC

Technical details

Sustainability certificatesENERGY STAR

Other features

Dimensions (WxDxH)150 x 180 x 86 mm
Power managementYes
Power over Ethernet (PoE)No
Redundant power supply (RPS) supportNo
Power rocker switchYes
