COUGAR GX 800

COUGAR GX 800

Model GX 800Part no. GX800EAN 4710918405748

48 specifications
  • ColourBlack, Gold
  • Total power800 W
  • Motherboard power connector20+4 pin ATX
  • PurposePC
  • Width150 mm
  • Sustainability certificatesENERGY STAR
See all specifications

Overview

Colour
Black, Gold
Total power
800 W
Motherboard power connector
20+4 pin ATX
Purpose
PC
Width
150 mm
Sustainability certificates
ENERGY STAR
Brand
COUGAR
Model
GX 800
Part number
GX800
EAN / UPC
4710918405748
Also known as
COUGAR GX 800 power supply unit 800 W 20+4 pin ATX ATX Black, Gold

Specifications

48 specifications in 8 groups

Power

Total power800 W
AC input voltage110 - 240 V
AC input frequency50 - 60 Hz
Input current10 A
Maximum input current (@110V)5 A
Maximum input current (@220V)10 A
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)160 W
Combined power (+12V)780 W
Combined power (+5V)160 W
Max output current (+3.3V)25 A
Max output current (+12V)50 A
Max output current (+12V1)50 A
Max output current (+12V2)50 A
Max output current (+5V)25 A
Max output current (-12V)0.8 A
Max output current (+5Vsb)4 A
Efficiency93%
Power protection featuresOver current, Over voltage, Overheating, Overload, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector20+4 pin ATX
Number of SATA power connectors10
Peripheral (Molex) power connectors (4-pin)4
PCI Express power connectors (8-pin)4
ATX power connector (20+4 pin)Yes
PCI Express connectorYes
Cabling typeSemi-Modular

Performance

PurposePC
Power supply unit (PSU) form factorATX
80 PLUS certification80 PLUS Gold
ATX version2.31
EPS version2.92
Bearing technologyBall bearing
Mean time between failures (MTBF)300000 h

Design

Product colourBlack, Gold
Cooling typeActive
Fan diameter14 cm
Number of fans1 fan(s)
Fan locationTop
On/off switchYes

Certificates

Compliance certificatesRoHS
CertificationCB,CE, FCC, CCC, TUV, RUus, R63088

Weight & dimensions

Width150 mm
Depth160 mm
Height86 mm

Technical details

Sustainability certificatesENERGY STAR

Other features

Mounting typeRack mounting
Parallel processing technology supportCrossFire
Power managementYes
