CLUB3D CSP-X1200CS power supply unit

CLUB3D CSP-X1200CS power supply unit

1200 W 20+4 pin ATX ATX Black, Blue

Model CSP-X1200CSEAN 5053866632699

50 specifications
  • Noise10 dB
  • Weight2.85 kg
  • ColourBlack, Blue
  • Total power1200 W
  • Motherboard power connector20+4 pin ATX
  • PurposePC
See all specifications

Overview

Noise
10 dB
Weight
2.85 kg
Colour
Black, Blue
Total power
1200 W
Motherboard power connector
20+4 pin ATX
Purpose
PC
Brand
CLUB3D
Model
CSP-X1200CS
Part number
CSP-X1200CS
EAN / UPC
5053866632699, 8717249409533
Also known as
CLUB3D CSP-X1200CS power supply unit 1200 W 20+4 pin ATX ATX Black, Blue

Specifications

50 specifications in 9 groups

Power

Total power1200 W
AC input voltage115 - 230 V
AC input frequency50 - 60 Hz
Input current15 A
Power factor0.99
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)170 W
Combined power (+12V)1179 W
Combined power (+5V)170 W
Combined power (-12V)21 W
Combined power (+5Vsb)21 W
Max output current (+3.3V)24 A
Max output current (+12V1)40 A
Max output current (+12V2)40 A
Max output current (+12V3)40 A
Max output current (+12V4)40 A
Max output current (+5V)30 A
Max output current (-12V)0.5 A
Max output current (+5Vsb)3 A
Efficiency88%
Power protection featuresOver current, Over power, Over voltage, Overload, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector20+4 pin ATX
Number of SATA power connectors9
Peripheral (Molex) power connectors (4-pin)7
PCI Express power connectors (6+2 pin)6
CPU power connector (4+4 pin)Yes
ATX power connector (20+4 pin)Yes
Floppy drive power connector2
Cabling typeSemi-Modular

Performance

PurposePC
Power supply unit (PSU) form factorATX
80 PLUS certification80 PLUS Silver
ATX version2.3
EPS version2.92
Noise level10 dB

Design

Product colourBlack, Blue
Cooling typeActive
Fan diameter13.5 cm
Number of fans1 fan(s)
On/off switchYes

Certificates

Compliance certificatesRoHS
CertificationCE, RoHS, FCC, 80+Silver

Weight & dimensions

Width150 mm
Depth165 mm
Height86 mm
Weight2.85 kg

Packaging data

ManualYes

Technical details

Sustainability certificatesENERGY STAR

Other features

Dimensions (WxDxH)150 x 165 x 86 mm
Parallel processing technology support2-Way SLI, 3-Way SLI, 4-Way CrossFireX, 4-Way SLI, Hybrid CrossFireX, Quad-GPU CrossFireX, Quad-GPU SLI
