Chieftec GPF-350P power supply unit
350 W 20+4 pin ATX TFX Silver
Model GPF-350PEAN 4710713234673
39 specifications
- ColourSilver
- Total power350 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width86 mm
Overview
- Colour
- Silver
- Total power
- 350 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 86 mm
- Brand
- Chieftec
- Category
- Power Supply Unit
- Model
- GPF-350P
- Part number
- GPF-350P
- EAN / UPC
- 4710713234673
- Also known as
- Chieftec GPF-350P power supply unit 350 W 20+4 pin ATX TFX Silver
Specifications
39 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 350 W |
| AC input voltage | 115 - 230 V |
| AC input frequency | 47 - 63 Hz |
| Input current | 6.3 A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 300 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 10 W |
| Max output current (+3.3V) | 16 A |
| Max output current (+12V1) | 15 A |
| Max output current (+12V2) | 15 A |
| Max output current (+5V) | 16 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2 A |
| Efficiency | 85% |
| Power protection features | Over voltage, Overload, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 2 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| CPU P4 connector (4-pin) | 1 |
| Floppy disk drive connector | Yes |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | TFX |
| ATX version | 2.3 |
| Bearing technology | Sleeve |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
| Fan diameter | 8 cm |
| Number of fans | 1 fan(s) |
| On/off switch | No |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, CB, TUV |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 86 mm |
| Depth | 175 mm |
| Height | 65 mm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
