Polaris 1250W power supply unit 20+4 pin ATX Black
Model 1250WPart no. PPS-1250FCEAN 753263077516
40 specifications
- Weight2.7 kg
- ColourBlack
- Total power1250 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width160 mm
Overview
- Weight
- 2.7 kg
- Colour
- Black
- Total power
- 1250 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 160 mm
- Brand
- Chieftec
- Category
- Power Supply Unit
- Model
- 1250W
- Part number
- PPS-1250FC
- EAN / UPC
- 753263077516
- Also known as
- Chieftec Polaris 1250W power supply unit 20+4 pin ATX Black
Specifications
40 specifications in 9 groups
Power
| Specification | Value |
|---|---|
| Total power | 1250 W |
| Peak power | 1250 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 15 - 8 A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 1250 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 0.3 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 22 A |
| Max output current (+12V1) | 104.1 A |
| Max output current (+5V) | 22 A |
| Max output current (-12V) | 3.6 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 65 cm |
| Number of SATA power connectors | 12 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| EPS power connector (4+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 6 |
| Cabling type | Fully-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| 80 PLUS certification | 80 PLUS Gold |
| ATX version | 2.3 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 14 cm |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 2.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 3.5 kg |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ErP |
| Sustainability compliance | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
