be quiet! Pure Power L7
Model Pure Power L7Part no. BN108EAN 4260052182444
50 specifications
- Noise26 dB
- Weight1.75 kg
- ColourBlack
- Total power530 W
- Motherboard power connector20+4 pin ATX
- PurposePC
Overview
- Noise
- 26 dB
- Weight
- 1.75 kg
- Colour
- Black
- Total power
- 530 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Brand
- be quiet!
- Category
- Power Supply Unit
- Model
- Pure Power L7
- Part numbers
- BN108, BN106, BN104, BN103, BN105, BN107
- EAN / UPC
- 4260052182444, 4260052181317, 4260052181324, 4260052181706 +9 more
- Also known as
- be quiet! Pure Power L7 power supply unit 530 W 20+4 pin ATX ATX Black
Specifications
50 specifications in 10 groups
Power
| Specification | Value |
|---|---|
| Total power | 530 W |
| Peak power | 580 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 7 - 3.5 A |
| Maximum input current (@110V) | +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V |
| Power factor | 0.99 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 W |
| Combined power (+12V) | 420 W |
| Combined power (+5V) | 130 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V) | 35 A |
| Max output current (+12V1) | 22 A |
| Max output current (+12V2) | 22 A |
| Max output current (+5V) | 24 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Efficiency | 86% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 5 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU P4 connector (4-pin) | 1 |
| Floppy drive power connector | 1 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS |
| ATX version | 2.3 |
| Noise level | 26 dB |
| Mean time between failures (MTBF) | 100000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Fan speed | 1650 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, CB, TÜV, Nemko (N), Semko (S), Fimko (FI), Demko (D) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 1.75 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 2.05 kg |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 185 x 145 x 163 mm |
