Dark Power 13
Model Dark Power 13Part no. BN334EAN 4260052189405
67 specifications
- Noise19.8 dB
- Weight1.97 kg
- ColourBlack
- Total power850 W
- Motherboard power connector20+4 pin ATX
- PurposePC
Overview
- Noise
- 19.8 dB
- Weight
- 1.97 kg
- Colour
- Black
- Total power
- 850 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Brand
- be quiet!
- Category
- Power Supply Unit
- Model
- Dark Power 13
- Part numbers
- BN334, BN333, BN335
- EAN / UPC
- 4260052189405, 4260052189399, 4260052189382
- Also known as
- be quiet! Dark Power 13 power supply unit 850 W 20+4 pin ATX ATX Black
Specifications
67 specifications in 11 groups
Power
| Specification | Value |
|---|---|
| Total power | 850 W |
| Peak power | 950 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 10 A |
| Maximum input current (@110V) | 5 A |
| Maximum input current (@220V) | 10 A |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V1) | 30 A |
| Max output current (+12V2) | 30 A |
| Max output current (+12V3) | 35 A |
| Max output current (+12V4) | 35 A |
| Max output current (+5V) | 24 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 95.4% |
| Hold time | 22.6 ms |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 60 cm |
| Number of PATA power connectors | 3 |
| Number of SATA power connectors | 12 |
| SATA power cable length | 1050 mm |
| Peripheral (Molex) power connectors (4-pin) | 0 |
| PCI Express power connectors (6-pin) | 0 |
| PCI Express power connectors (6+2 pin) | 4 |
| CPU P4 connector (4-pin) | 0 |
| CPU power connector (4+4 pin) | Yes |
| PCI Express connector | Yes |
| Cabling type | Fully-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Titanium |
| Supported motherboard form factors | ATX, micro ATX, Mini-ATX |
| ATX version | 3.0 |
| EPS version | 2.92 |
| Noise level | 19.8 dB |
| Bearing technology | FDB |
| Mean time between failures (MTBF) | 100000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Number of fans | 1 fan(s) |
| Fan speed | 0 - 1800 RPM |
| Fan location | Top |
| Built-in display | No |
| Illumination | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Packaging content
| Specification | Value |
|---|---|
| Cables included | SATA |
| Cable tie(s) included | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CB, CCC, CE, Federal Communications Commission (FCC), RoHS, UKCA, WEEE |
| Certification | BSMI, CB, CCC, CE, cRUus, CU, FCC, cTUVus, RCM, TUV, UKCA, Triman |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 175 mm |
| Height | 86 mm |
| Weight | 1.97 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 120 mm |
| Package depth | 350 mm |
| Package height | 270 mm |
| Package weight | 4.25 kg |
| Package type | Box |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR, ErP |
Logistics data
| Specification | Value |
|---|---|
| Shipping (inner) case height | 36.8 cm |
| Shipping (inner) case length | 50.4 cm |
| Shipping (inner) case net weight | 18.3 kg |
| Shipping (inner) case width | 30.5 cm |
| Warranty period | 10 year(s) |
