Aerocool VX-400 power supply unit
400 W 20+4 pin ATX Black
Model VX-400Part no. AE-VX400EAN 4713105953541
32 specifications
- Noise30.6 dB
- ColourBlack
- Total power400 W
- Motherboard power connector20+4 pin ATX
- PurposePC
Overview
- Noise
- 30.6 dB
- Colour
- Black
- Total power
- 400 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Brand
- Aerocool
- Category
- Power Supply Unit
- Model
- VX-400
- Part number
- AE-VX400
- EAN / UPC
- 4713105953541, 8697939896280
- Also known as
- Aerocool VX-400 power supply unit 400 W 20+4 pin ATX Black
Specifications
32 specifications in 5 groups
Power
| Specification | Value |
|---|---|
| Total power | 400 W |
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
| Input current | 4 A |
| Maximum input current (@110V) | +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V |
| Power factor | 0.99 |
| Power Factor Correction (PFC) type | Active |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V1) | 18 A |
| Max output current (+12V2) | 17 A |
| Max output current (+5V) | 18 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Power protection features | Over power, Over voltage, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 2 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| PCI Express power connectors (6-pin) | 1 |
| CPU power connector (4+4 pin) | Yes |
| ATX power connector (20+4 pin) | Yes |
| Floppy drive power connector | 1 |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| ATX version | 2.3 |
| Noise level | 30.6 dB |
| Mean time between failures (MTBF) | 120000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, FCC |
