Aerocool Strike-X Army
Model Strike-X ArmyPart no. STRIKEX1100ARMYEAN 4713105953039
41 specifications
- Weight1.8 kg
- ColourBlack, Green
- Total power1100 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width150 mm
Overview
- Weight
- 1.8 kg
- Colour
- Black, Green
- Total power
- 1100 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 150 mm
- Brand
- Aerocool
- Category
- Power Supply Unit
- Model
- Strike-X Army
- Part numbers
- STRIKEX1100ARMY, STRIKEX800ARMY
- EAN / UPC
- 4713105953039, 4713105953022
- Also known as
- Aerocool Strike-X Army power supply unit 1100 W 20+4 pin ATX Black, Green
Specifications
41 specifications in 8 groups
Power
| Specification | Value |
|---|---|
| Total power | 1100 W |
| AC input voltage | 115 - 230 V |
| Input current | 15 A |
| Maximum input current (@110V) | +12V,+3.3V,+5V,+5Vsb,-12V |
| Power factor | 0.99 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 170 W |
| Combined power (+12V) | 1080 W |
| Combined power (+5V) | 170 W |
| Combined power (-12V) | 6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V) | 90 A |
| Max output current (+5V) | 30 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 8 |
| PCI Express power connectors (6+2 pin) | 6 |
| CPU power connector (4+4 pin) | Yes |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 2 |
| Cabling type | Semi-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| 80 PLUS certification | 80 PLUS Gold |
| Mean time between failures (MTBF) | 120000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Green |
| Cooling type | Active |
| Fan diameter | 13.9 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, FCC, TUV, Gost, CB |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 165 mm |
| Height | 86 mm |
| Weight | 1.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Warranty card | Yes |
