Aerocool Imperator power supply unit
550 W 20+4 pin ATX ATX Black, White
Model ImperatorPart no. EN50135EAN 4710700950173
40 specifications
- ColourBlack, White
- Total power550 W
- Motherboard power connector20+4 pin ATX
- PurposePC
Overview
- Colour
- Black, White
- Total power
- 550 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Brand
- Aerocool
- Category
- Power Supply Unit
- Model
- Imperator
- Part numbers
- EN50135, EN50142, EN53945, EN53952
- EAN / UPC
- 4710700950173
- Also known as
- Aerocool Imperator power supply unit 550 W 20+4 pin ATX ATX Black, White
Specifications
40 specifications in 5 groups
Power
| Specification | Value |
|---|---|
| Total power | 550 W |
| AC input voltage | 230 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 15 A |
| Maximum input current (@110V) | +12V,+3.3V,+5V,+5Vsb,-12V |
| Power factor | 0.99 |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 420 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V) | 35 A |
| Max output current (+5V) | 24 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 85% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 4 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| ATX power connector (20+4 pin) | Yes |
| Floppy drive power connector | 1 |
| Cabling type | Semi-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Bronze |
| ATX version | 2.3 |
| EPS version | 2.92 |
| Mean time between failures (MTBF) | 120000 h |
| Compatible products | Dual Core CPU, ATI CrossFire, NVIDIA SLi, Multi-Core GPU technologies |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Cooling type | Active |
| Fan diameter | 13.9 cm |
| Number of fans | 1 fan(s) |
| Fan location | Side |
| On/off switch | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, CB, TUV |
