AEROW550 PC Power Supply
550W 80 Plus White 230V Silent Black
Model AeroPart no. AEROB750EAN 4710562754001
32 specifications
- ColourBlack
- Total power550 W
- Number of PATA power connectors3
- PurposePC
Overview
- Colour
- Black
- Total power
- 550 W
- Number of PATA power connectors
- 3
- Purpose
- PC
- Brand
- Aerocool
- Category
- Power Supply Unit
- Model
- Aero
- Part numbers
- AEROB750, AEROW550, AEROW650, AEROB550, AEROB650
- EAN / UPC
- 4710562754001, 4710562753912, 4710562753936, 4710562753967 +1 more
- Also known as
- Aerocool AEROW550 PC Power Supply 550W 80 Plus White 230V Silent Black
Specifications
32 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 550 W |
| AC input voltage | 200 - 240 V |
| AC input frequency | 47 - 63 Hz |
| Input current | 4.5 A |
| Combined power (+3.3V) | 110 W |
| Combined power (+12V) | 504 W |
| Combined power (+5V) | 110 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 19 A |
| Max output current (+12V) | 42 A |
| Max output current (+5V) | 19 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
Ports & interfaces
| Specification | Value |
|---|---|
| Number of PATA power connectors | 3 |
| Number of SATA power connectors | 5 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| ATX power connector (20+4 pin) | Yes |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| 80 PLUS certification | 80 PLUS White |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging data
| Specification | Value |
|---|---|
| Package width | 250 mm |
| Package depth | 495 mm |
| Package height | 215 mm |
| Package type | Box |
Other features
| Specification | Value |
|---|---|
| Power management | Yes |
