AB231301 power supply unit
1300 W 20+4 pin ATX ATX Black
Model AB231301EAN 18436617921374
37 specifications
- Weight1.65 kg
- ColourBlack
- Total power1300 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width140 mm
Overview
- Weight
- 1.65 kg
- Colour
- Black
- Total power
- 1300 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 140 mm
- Brand
- ABYSM
- Category
- Power Supply Unit
- Model
- AB231301
- Part number
- AB231301
- EAN / UPC
- 18436617921374, 8436617921377
- Also known as
- ABYSM AB231301 power supply unit 1300 W 20+4 pin ATX ATX Black
Specifications
37 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 1300 W |
| AC input voltage | 100 - 240 V |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over voltage, Under voltage, Over power, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 12 |
| SATA power cable length | 450,570,690,810 mm |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| Peripheral (Molex) power cable length | 450,570,690,810 mm |
| EPS power connector (4+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power cable length | 70 cm |
| Number of EPS connectors | 2 |
| PCI Express connector | Yes |
| Cabling type | Fully-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | No |
| EPS version | 3.1 |
| Bearing technology | FDB |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, EuP |
| Certification | Cybenetics Platinum |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 150 mm |
| Height | 85 mm |
| Weight | 1.65 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 310 mm |
| Package depth | 220 mm |
| Package height | 120 mm |
| Package weight | 3.79 kg |
