T1A ED 800 CTM I5-4570 128/8 W10 REFURBISHED

Model ED 800 CTM I5-4570 128/8 W10 REFURBISHEDPart no. D-HPED800-MU-C022EAN 5711603025066

90 specifications

Overview

Brand: T1A
Category: PCs/Workstations
Model: ED 800 CTM I5-4570 128/8 W10 REFURBISHED
Part number: D-HPED800-MU-C022
EAN / UPC: 5711603025066
Also known as: T1A ED 800 CTM I5-4570 128/8 W10 REFURBISHED Intel® Core™ i5 8 GB DDR3-SDRAM 128 GB SSD Windows 10 Pro SFF PC Black

90 specifications in 11 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	4th gen Intel® Core™ i5
Processor model	i5-4570
Processor cores	4
Processor threads	4
Processor boost frequency	3.6 GHz
Processor frequency	3.2 GHz
Processor cache	6 MB
Processor cache type	Smart Cache
Bus type	DMI2
System bus rate	5 GT/s
Processor lithography	28 nm
Processor operating modes	64-bit
Thermal Design Power (TDP)	84 W
Tcase	72.72 °C
Maximum number of PCI Express lanes	16
PCI Express configurations	1x16, 2x8, 1x8+2x4
PCI Express slots version	3.0
Number of QPI links	0
Processor socket	LGA 1150 (Socket H3)
Maximum internal memory supported by processor	32 GB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333,1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s

Specification	Value
Discrete graphics card	Yes
On-board graphics card	Yes
Discrete GPU manufacturer	AMD
On-board graphics card model	Intel® HD Graphics 4600
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Graphics card HDMI ports quantity	1
Graphics card VGA (D-Sub) ports quantity	1

Specification	Value
Product type	PC

Specification	Value
Ethernet LAN	Yes

Specification	Value
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
Headphone outputs	1

Specification	Value
Chassis type	SFF
Product colour	Black

Specification	Value
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel FDI Technology	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel TSX-NI	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Wireless Display (Intel® WiDi)	Yes
Processor package size	37.5 x 37.5 mm
Scalability	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes
Thermal solution specification	PCG 2013D
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Anti-Theft Technology (Intel® AT)	Yes
