Presence Small Space Solution with Zoom Rooms
Model Presence Small Space Solution with Zoom RoomsPart no. 643J5AWEAN 196548107650
69 specifications
- ProcessorIntel® Core™ i5
- Memory8 GB
- Storage256 GB
- TypeGroup video conferencing system
- OSWindows 10 IoT Enterprise
- Weight1.42 kg
Overview
- Processor
- Intel® Core™ i5
- Memory
- 8 GB
- Storage
- 256 GB
- Type
- Group video conferencing system
- OS
- Windows 10 IoT Enterprise
- Weight
- 1.42 kg
- Brand
- HP
- Category
- PCs/Workstations
- Model
- Presence Small Space Solution with Zoom Rooms
- Part number
- 643J5AW
- EAN / UPC
- 196548107650, 196548060139, 196548107452, 196548107469 +16 more
- Also known as
- HP Presence Small Space Solution with Zoom Rooms Intel® Core™ i5 i5-10500T 8 GB DDR4 256 GB SSD Windows 10 IoT Enterprise Group video conferencing system
Specifications
69 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor generation | 10th gen Intel® Core™ i5 |
| Processor model | i5-10500T |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor boost frequency | 3.8 GHz |
| Processor frequency | 2.3 GHz |
| Processor cache | 12 MB |
| Processor cache type | L3 |
| Configurable TDP-down | 25 W |
| Configurable TDP-down frequency | 1.7 GHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR4 |
| Memory layout (slots x size) | 2 x 4 GB |
| Memory slots | 2x DIMM |
| Memory clock speed | 2666 MHz |
| ECC | No |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 256 GB |
| Storage media | SSD |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| NVMe | Yes |
| SSD interface | PCI Express, NVMe |
| SSD form factor | M.2 |
Performance
| Specification | Value |
|---|---|
| Product type | Group video conferencing system |
| Password protection | Yes |
| Password protection type | BIOS, Power on, User |
| Built-in speaker(s) | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| WLAN controller manufacturer | Intel |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 IoT Enterprise |
| Pre-installed software | HP Privacy Settings; Zoom Rooms; HP Desktop Support Utilities; HP TechPulse; HP Presence Smart Setup; HP Cloud Endpoint Manager; HP Presence App |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Brand-specific features
| Specification | Value |
|---|---|
| HP Security tools | HP Wolf Security for Business includes: HP Sure Start Gen7, HP Secure Erase |
Audio
| Specification | Value |
|---|---|
| Number of speakers | 2 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.42 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 576 mm |
| Package depth | 281 mm |
| Package height | 246 mm |
| Package weight | 5.5 kg |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Sustainable technologies and materials | Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; Ocean-bound plastic in speaker enclosure, I/O strip and bezel frame; Recycled Plastic cushions |
| Sustainability compliance | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8517620000 |
