Compaq dc7900 Convertible Minitower PC (ENERGY STAR)
Model Compaq dc7900 Convertible Minitower PC (ENERGY STAR)Part no. FU031ET#ABU? L2245WGEAN 884420281672
130 specifications
- ProcessorIntel® Core™2 Duo
- Memory2 GB
- Storage250 GB
- GraphicsAMD Radeon HD 3650
- TypePC
- OSWindows Vista Business
Overview
- Processor
- Intel® Core™2 Duo
- Memory
- 2 GB
- Storage
- 250 GB
- Graphics
- AMD Radeon HD 3650
- Type
- PC
- OS
- Windows Vista Business
- Brand
- HP
- Category
- PCs/Workstations
- Model
- Compaq dc7900 Convertible Minitower PC (ENERGY STAR)
- Part numbers
- FU031ET#ABU? L2245WG, FS485AW#ABH, FS483AW#ABH, FS483AW, FS484AW, FU031ET#ABU? L2445W +34 more
- EAN / UPC
- 884420281672, 884420280873, 884420280880, 884420280897 +56 more
- Also known as
- HP Compaq dc7900 Convertible Minitower PC (ENERGY STAR) Intel® Core™2 Duo E8500 2 GB DDR2-SDRAM 250 GB AMD Radeon HD 3650 Windows Vista Business
Specifications
130 specifications in 22 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™2 Duo |
| Processor model | E8500 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 3.16 GHz |
| Processor cache | 6 MB |
| Processor cache type | L2 |
| Processor front side bus | 1333 MHz |
| Bus type | FSB |
| FSB Parity | No |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Core 2 Duo E8000 Series |
| Processor codename | Wolfdale |
| Processor system type | DP |
| Thermal Design Power (TDP) | 65 W |
| Tcase | 72.4 °C |
| Processor socket | LGA 775 (Socket T) |
| Number of Processing Die Transistors | 410 M |
| Processing Die size | 107 mm² |
| CPU multiplier (bus/core ratio) | 9.5 |
| Processor core voltage (AC) | 0.850/1.3625 V |
| Stepping | C0 |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
| Internal memory type | DDR2-SDRAM |
| Memory clock speed | 800 MHz |
| Minimum RAM | 512 MB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 250 GB |
| Optical drive type | DVD Super Multi |
| HDD capacity | 250 GB |
| HDD speed | 7200 RPM |
| Card reader integrated | Yes |
| Maximum HDD capacity | 500 GB |
| Minimum storage drive space | 80 GB |
| Storage drive controller | SATA 3.0GB/s with NCQ and Smart IV |
| Diskette drive | Optional |
| Storage drive type | 250 GB |
| HDD controller type | SATA (7200 rpm) |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card model | AMD Radeon HD 3650 |
| Video card features | 3D/2D Controller: support is fully compliant with Microsoft standard API such as Microsoft DirectX9, DirectXVA, VMR9, GDI/GDI+; OpenGL 1.4.; Integrated VGA Controller; Integrated 400 MHz RAMDAC; Overlay Planes: Single overlay support with 5x3 filtering; Maximum Color Depth: 32 bits/pixel; Multi-disp |
| Video adapter, bus | PCI Express x16 |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
Optical drive
| Specification | Value |
|---|---|
| LightScribe | Yes |
Network
| Specification | Value |
|---|---|
| Networking features | Integrated Intel 82567LM Gigabit Network Connection |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 8 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 2 |
| Serial ports quantity | 1 |
| Parallel ports quantity | 0 |
| I/O ports | Rear: 6 USB 2.0, 1 serial port, 2 PS/2, 1 RJ-45, 1 VGA, 1 DisplayPort, audio in/out; Front: 2 USB 2.0, audio ports; Optional: 2nd serial port, 1 parallel port |
| Rear ports note | 6 USB 2.0; 1 serial; 2 PS/2; 1 RJ-45; 1 external VGA monitor; 1 DisplayPort; 1 audio in; 1 audio out; 1 parallel (optional); 1 serial (optional 2nd); 1 eSATA (optional) |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 slots | 1 |
| PCI Express x16 slots | 1 |
| Expansion slots | 3 full-height PCI, 1 full-height PCI Express x16, 2 full-height PCI Express x1 |
Power
| Specification | Value |
|---|---|
| Power supply type | 365W 85% Efficient - Active PFC |
| Power requirements | Input voltage 90 – 264 / 100 – 240 VAC, 50/60 Hz, 47 – 63 Hz, active PFC (85% High Efficiency) Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current: 6.0 A; Rated Input Current 80 Plu |
| Power consumption (typical) | 365 W |
Design
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| External drive bays | 3 x 5.25", 1 x 3.5" |
| Country of origin | China |
| Upgrade type | Windows Vista capable |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Vista Business |
| Applications supported | Windows Vista Premium ready |
| Compatible operating systems | Genuine Windows XP Professional; Genuine Windows XP Home |
| Bundled software | On some models only (not included with FreeDOS): HP ProtectTools Security Software Suite Version 4.0, HP Power Manager, HP Firefox Virtual Browser, HP Backup and Recovery Manager, HP Insight Diagnostics Software (available via HP Backup and Recovery Manager), Computer Setup Utility, McAfee AntiVirus |
| Driver LAN | Microsoft Windows Vista, Microsoft Windows XP |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 33911 |
| Processor code | SLAPK |
| Processor package size | 37.5 x 37.5 mm |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Conflict-Free processor | No |
Audio
| Specification | Value |
|---|---|
| Audio system | Integrated HD audio with ADI1884 codec, internal PC speaker |
| Audio included | Integrated HD audio with ADI1884 codec, internal PC speaker |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Relative humidity | 10 - 90% |
| Non-operating altitude | 9144 |
| Operating temperature (T-T) | 50 - 95 °F |
| Non-operating relative humidity (non-condensing) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 177 mm |
| Depth | 452 mm |
| Height | 447 mm |
| Weight | 11.8 kg |
| Size (imperial) | 17.8 cm (7") |
| Weight (imperial) | 26.2 lb |
Certificates
| Specification | Value |
|---|---|
| Certification | ENERGY STAR qualified; EPEAT Gold; 85% efficient power supply |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | HP PS/2 2-Button Optical Scroll Mouse |
| Keyboard type | HP PS/2 Standard Keyboard |
Multimedia
| Specification | Value |
|---|---|
| Multimedia | Integrated High Definition audio with ADI1884 codec (all ports are stereo) |
Features
| Specification | Value |
|---|---|
| Manageability features | Long, stable lifecycle. Expandable, convertible chassis. |
| Security management description | Integrated 1.2 TPM Embedded Security Chip (except for Russia), HP Business PC Security Lock, HP USB Smartcard Keyboard |
Other features
| Specification | Value |
|---|---|
| Security features | Kensington Lock, Solenoid Hood Lock / Sensor |
| Drive bays | 3 external 5.25 inch, 1 external 3.5 inch 2 internal 3.5 inch |
