i7-9700 CPU
16GB RAM, 2x250GB SSD RAID1, 2TB, Windows 10 Pro
Model CORE-EASYVIEW-MASTEREAN 5704174386407
48 specifications
- ProcessorIntel® Core™ i7
- Memory16 GB
- Storage2 TB
- OSWindows 10
- Weight18.9 kg
- Processor manufacturerIntel
Overview
- Processor
- Intel® Core™ i7
- Memory
- 16 GB
- Storage
- 2 TB
- OS
- Windows 10
- Weight
- 18.9 kg
- Processor manufacturer
- Intel
- Brand
- Ernitec
- Category
- Network Surveillance Server
- Model
- CORE-EASYVIEW-MASTER
- Part number
- CORE-EASYVIEW-MASTER
- EAN / UPC
- 5704174386407
- Also known as
- Ernitec i7-9700 CPU, 16GB RAM, 2x250GB SSD RAID1, 2TB, Windows 10 Pro
Specifications
48 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor frequency | 3 GHz |
| Processor cores | 8 |
| Processor threads | 8 |
| Processor boost frequency | 4.7 GHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4 |
Storage
| Specification | Value |
|---|---|
| Number of HDDs supported | 4 |
| Hot-swap drive bays | Yes |
| Total storage capacity | 2 TB |
| HDD capacity | 2 TB |
| SSD capacity | 250 GB |
| Number of HDDs installed | 1 |
| Number of SSDs installed | 2 |
| RAID support | Yes |
| RAID levels | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| DVI-D ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 3 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| VGA (D-Sub) output ports | 1 |
| AC-in ports quantity | 2 |
| PS/2 ports quantity | 2 |
| Audio in/out | Yes |
Features
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack |
| Rack capacity | 1U |
| LED indicators | Yes |
| Number of fans | 3 fan(s) |
Power
| Specification | Value |
|---|---|
| Power supply | 400 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Sustainability compliance | Yes |
| Warranty period | 3 year(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 437 mm |
| Depth | 503 mm |
| Height | 43 mm |
| Weight | 18.9 kg |
| Package width | 594 mm |
| Package depth | 754 mm |
| Package height | 216 mm |
| Package weight | 19 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 8 - 90% |
Packaging content
| Specification | Value |
|---|---|
| Rack mount kit | Yes |
| Cables included | AC |
