Deco M3W
Model Deco M3WPart no. DECO M3W
31 specifications
- Memory128 MB
- TypeNetwork transmitter
- ColourWhite
- Antennas quantity2
- Wi-FiYes
- AC input voltage100 - 240 V
Overview
- Memory
- 128 MB
- Type
- Network transmitter
- Colour
- White
- Antennas quantity
- 2
- Wi-Fi
- Yes
- AC input voltage
- 100 - 240 V
- Brand
- TP-Link
- Category
- Network Extender
- Model
- Deco M3W
- Part number
- DECO M3W
- Also known as
- TP-Link Deco M3W Network transmitter White
Specifications
31 specifications in 11 groups
Performance
| Specification | Value |
|---|---|
| Type | Network transmitter |
| Data transfer rate | 867 Mbit/s |
Antenna
| Specification | Value |
|---|---|
| Antennas quantity | 2 |
| Antenna type | Internal |
| Transmit power range | 20 - 30 dBmW |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi data rate (max) | 1167 Mbit/s |
| Quality of Service (QoS) support | Yes |
| Security algorithms | WPA-PSK, WPA2-PSK |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Yes |
| Reset button | Yes |
| Certification | CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 0.3 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 124 mm |
| Depth | 69 mm |
| Height | 35 mm |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Quick start guide | Yes |
Features
| Specification | Value |
|---|---|
| Internal memory | 128 MB |
| Flash memory | 8 MB |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
