AC1200 Wi-Fi
Model AC1200 Wi-FiPart no. RE315EAN 840030701498
49 specifications
- SpeedWi-Fi 5 (802.11ac)
- TypeNetwork repeater
- Weight150 g
- ColourWhite
- Antennas quantity2
- Ethernet LAN interface typeFast Ethernet
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- Network repeater
- Weight
- 150 g
- Colour
- White
- Antennas quantity
- 2
- Ethernet LAN interface type
- Fast Ethernet
- Brand
- TP-Link
- Category
- Network Extender
- Model
- AC1200 Wi-Fi
- Part number
- RE315
- EAN / UPC
- 840030701498, 1210002613965, 6935364072445, 6935364072452
- Also known as
- TP-Link AC1200 Mesh Wi-Fi Range Extender
Specifications
49 specifications in 12 groups
Performance
| Specification | Value |
|---|---|
| Type | Network repeater |
| Data transfer rate | 867 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| WPS push button | Yes |
| Windows operating systems supported | Yes |
| Mac compatibility | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
Antenna
| Specification | Value |
|---|---|
| Antennas quantity | 2 |
| Antenna type | External |
| Transmitting power (CE) | 2.4 GHz ≤20dBm, 5 GHz ≤30dBm |
Network
| Specification | Value |
|---|---|
| Ethernet LAN interface type | Fast Ethernet |
| Cabling technology | 10/100Base-T(X) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi data rate (max) | 1167 Mbit/s |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| WLAN data transfer rate (second band) | 867 Mbit/s |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Yes |
| Quantity per pack | 1 pc(s) |
| Country of origin | China |
| Reset button | Yes |
| Certification | CE, RoHS |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 9.5 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 64.8 mm |
| Depth | 124.1 mm |
| Height | 89 mm |
| Weight | 150 g |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
| Package width | 90.5 mm |
| Package depth | 158 mm |
| Package height | 123 mm |
| Package weight | 270 g |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Customs product code (TARIC) | 8517620000 |
