Nighthawk X6
Model Nighthawk X6Part no. EX7700-100PESEAN 606449136517
29 specifications
- TypeNetwork transmitter
- Weight530 g
- ColourBlack
- Cabling technology10/100/1000Base-T(X)
- Ethernet LAN (RJ-45) ports2
- Hidden Service Set Identifier (SSID)Yes
Overview
- Type
- Network transmitter
- Weight
- 530 g
- Colour
- Black
- Cabling technology
- 10/100/1000Base-T(X)
- Ethernet LAN (RJ-45) ports
- 2
- Hidden Service Set Identifier (SSID)
- Yes
- Brand
- NETGEAR
- Category
- Network Extender
- Model
- Nighthawk X6
- Part numbers
- EX7700-100PES, EX7700-100NAS, EX7700-100UKS
- EAN / UPC
- 606449136517, 606449136500, 606449136159
- Also known as
- NETGEAR Nighthawk X6 Network transmitter Black 10, 100, 1000 Mbit/s
Specifications
29 specifications in 10 groups
Performance
| Specification | Value |
|---|---|
| Type | Network transmitter |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| WPS push button | Yes |
| Browser supported | Internet Explorer 8.0+, Firefox 20+, Safari 5.1+, Chrome 25.0+ |
Network
| Specification | Value |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi data rate (max) | 2200 Mbit/s |
| Modulation | 256-QAM |
| Security algorithms | WEP, WPA, WPA2-PSK |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | LAN, Link, Power, WPS |
| On/off switch | Yes |
Management features
| Specification | Value |
|---|---|
| Hidden Service Set Identifier (SSID) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 199 mm |
| Depth | 54 mm |
| Height | 154 mm |
| Weight | 530 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
