8GB 3600MHz DDR4
Model 8GB 3600MHz DDR4Part no. HX436C17PB3A/8EAN 740617283815
35 specifications
- Memory8 GB
- Weight63.8 g
- Operating temperature (T-T)0 - 85 °C
- Windows operating systems supportedYes
- Width133.3 mm
Overview
- Memory
- 8 GB
- Weight
- 63.8 g
- Operating temperature (T-T)
- 0 - 85 °C
- Windows operating systems supported
- Yes
- Width
- 133.3 mm
- Brand
- HyperX
- Category
- Memory Module
- Model
- 8GB 3600MHz DDR4
- Part numbers
- HX436C17PB3A/8, HX436C17PB3/8
- EAN / UPC
- 740617283815, 740617283853
- Also known as
- HyperX Predator 8GB 3600MHz DDR4 memory module 1 x 8 GB 288-pin DIMM
Specifications
35 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Memory layout (modules x size) | 1 x 8 GB |
| Internal memory type | DDR4 |
| Component for | PC/Server |
| Memory form factor | 288-pin DIMM |
| ECC | No |
| CAS latency | 17 |
| Memory clock speed | 3600 MHz |
| Memory voltage | 1.2,1.35 V |
| Module configuration | 2048M x 64 |
| Intel Extreme Memory Profile (XMP) | Yes |
| Intel Extreme Memory Profile (XMP) version | 2.0 |
| Programming power voltage (VPP) | 2.5 V |
| Compatible chipsets | Intel® B150, Intel® H110, Intel® H170, Intel Q150, Intel® Q170, Intel® X99, Intel® Z170 |
| Cooling type | Heatsink |
| Lead plating | Gold |
| JEDEC standard | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 85 °C |
| Storage temperature (T-T) | -55 - 100 °C |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 133.3 mm |
| Depth | 8.3 mm |
| Height | 42.2 mm |
| Weight | 63.8 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 14 mm |
| Package depth | 57.1 mm |
| Package height | 171.4 mm |
| Package weight | 83 g |
| Package type | Retail pack |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 25 pc(s) |
| Master (outer) case width | 311.1 mm |
| Master (outer) case length | 196.8 mm |
| Master (outer) case height | 60.9 mm |
| Master (outer) case gross weight | 2.2 kg |
