00121783 Low Noise Block downconverter (LNB) 10.7
12.75 GHz White
Model 00121783EAN 4047443393784
12 specifications
- ColourWhite
- Input frequency range10.7 - 12.75 GHz
- RF connector typeF
- Power consumption80 mA
- Feedhorn diameter4 cm
Overview
- Colour
- White
- Input frequency range
- 10.7 - 12.75 GHz
- RF connector type
- F
- Power consumption
- 80 mA
- Feedhorn diameter
- 4 cm
- Brand
- Hama
- Model
- 00121783
- Part number
- 00121783
- EAN / UPC
- 4047443393784
- Also known as
- Hama 00121783 Low Noise Block downconverter (LNB) 10.7 - 12.75 GHz White
Specifications
12 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| Input frequency range | 10.7 - 12.75 GHz |
| Output frequency range | 1100-2150 MHz |
| Oscillator frequency | 10,6 GHz (L2)/9.75 GHz (L1) |
| Product colour | White |
Ports & interfaces
| Specification | Value |
|---|---|
| RF connector type | F |
Power
| Specification | Value |
|---|---|
| Power consumption | 80 mA |
Weight & dimensions
| Specification | Value |
|---|---|
| Feedhorn diameter | 4 cm |
Packaging data
| Specification | Value |
|---|---|
| Quantity | 1 |
| Package width | 102 mm |
| Package depth | 59 mm |
| Package height | 59 mm |
| Package weight | 84 g |
