TT84CA0BCB Black Built-in

80 cm Zone induction hob 4 zone(s) Built-in hood

Model TT84CA0BCBPart no. 949 598 634EAN 7333394131153

71 specifications

Overview

Brand: AEG
Category: Hob
Model: TT84CA0BCB
Part number: 949 598 634
EAN / UPC: 7333394131153
Also known as: AEG TT84CA0BCB Black Built-in 80 cm Zone induction hob 4 zone(s) Built-in hood

71 specifications in 7 groups

Specification	Value
Product colour	Black
Appliance placement	Built-in
Hob width size	80 cm
Hob type	Zone induction hob
Top surface type	Glass-ceramic
Number of cooking zones	4 zone(s)
Number of electric cooking zones	4 zone(s)
Cooking zone 1 type	Induction
Cooking zone 1 boost	3200 W
Cooking zone 1 diameter	210 mm
Cooking zone 1 position	Left front
Cooking zone 1 power	2300 W
Cooking zone 1 power source	Electric
Cooking zone 1 shape	Round
Cooking zone 2 type	Induction
Cooking zone 2 diameter	210 mm
Cooking zone 2 position	Left rear
Cooking zone 2 power source	Electric
Cooking zone 2 shape	Round
Cooking zone 2 boost	3200 W
Cooking zone 2 power	2300 W
Cooking zone 3 type	Induction
Cooking zone 3 diameter	145 mm
Cooking zone 3 position	Right front
Cooking zone 3 power source	Electric
Cooking zone 3 shape	Round
Cooking zone 3 boost	2500 W
Cooking zone 3 power	1400 W
Cooking zone 4 type	Induction
Cooking zone 4 diameter	180 mm
Cooking zone 4 position	Right rear
Cooking zone 4 power source	Electric
Cooking zone 4 shape	Round
Cooking zone 4 boost	2800 W
Cooking zone 4 power	1800 W
Frame type	Frameless

Specification	Value
Boost function	Yes
Number of power levels	9

Specification	Value
Built-in hood	Yes
Type of extraction	Ducted/Recirculating
Maximum extraction power	650 m³/h
Fan noise level (min)	50 dB
Fan noise level (max)	66 dB
Noise level (intensive speed)	69 dB
Grease filter type	Carbon
Lighting efficiency class	No
Energy efficiency class (hood)	A+
Energy efficiency scale	A+++ to D
Fluid dynamic efficiency class	A
Grease filtering efficiency class	B
Annual energy consumption	32.7 kWh
Fluid dynamic efficiency (FDE)	32
Grease filtering efficiency (GFE)	85.1%

Specification	Value
Width	800 mm
Weight	17.6 kg
Cord length	1.5 m
Installation compartment width	78 cm
Installation compartment depth	49 cm
Installation compartment height	22.5 cm
