Zebra Motorola MC45 handheld mobile computer: Full Specifications

Overview

Display: 8.13 cm (3.2")
Resolution: 240 x 320 pixels
Processor: ARM11
Memory: 0.256 GB
Camera: 3.2 MP
Battery: 3080 mAh

Brand: Zebra
Category: Handheld Mobile Computer
Model: MC45
Part numbers: MC4597-AAPBG0000, MC4597-AAPBI0000, MC4597-AAPBS0000, MC45N7-ABPBA0200, MC4597-AAPBA0000, MC4597-BAPBA0000 +1 more
EAN / UPC: 4056572638055, 5711783490227, 4056572404759, 5712505802243
Also known as: Motorola MC45 handheld mobile computer 8.13 cm (3.2") 240 x 320 pixels Touchscreen 247 g Black

Specifications

44 specifications in 13 groups

Display

Specification	Value
Display diagonal	8.13 cm (3.2")
Display resolution	240 x 320 pixels
Touchscreen	Yes

Memory

Specification	Value
Internal memory	0.256 GB
Internal memory type	RAM
Flash memory	1 GB
Compatible memory cards	MicroSD (TransFlash), SDHC
Maximum memory card size	32 GB

Processor

Specification	Value
Processor frequency	0.6 GHz
Processor family	ARM11

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth	Yes
Bluetooth version	2.0+EDR
Data network	3.5G, Edge, GPRS, GSM, HSDPA
GSM bands supported	850,900,1800,1900 MHz
Security algorithms	128-bit WEP, 40-bit WEP, CCX v4, LEAP, TKIP, WEP, WPA2

GPS Performance

Specification	Value
GPS (satellite)	Yes

Camera

Specification	Value
Built-in camera	Yes
Rear camera resolution (numeric)	3.2 MP
Auto focus	Yes
Built-in flash	Yes

Audio

Specification	Value
Built-in microphone	Yes

Performance

Specification	Value
Product colour	Black
Barcode reader	Yes
RFID reader	No
Phone function	Yes
E-mail	Yes
Multimedia Messaging Service (MMS)	Yes
Personal info management (PIM)	Alarm clock, Calculator, Calendar
Vibrating alert	Yes
Certification	FCC, RSS, UL, IEC, CSA, ICES, RoHS, WEEE

Software

Specification	Value
Operating system installed	Windows Embedded Handheld 6.5.3

Weight & dimensions

Specification	Value
Weight	247 g
Width	66 mm
Depth	25 mm
Height	142 mm

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	14 - 122 °F
Relative humidity	5 - 95%

Battery

Specification	Value
Battery capacity	3080 mAh
Battery technology	Lithium-Ion (Li-Ion)

Logistics data

Specification	Value
Harmonized System (HS) code	84713000
