Zebra MC3300ax handheld mobile computer: Full Specifications

Overview

Display: 10.2 cm (4")
Resolution: 800 x 480 pixels
Processor: Snapdragon
Memory: 4 GB
Battery: 7000 mAh
OS: Android

Brand: Zebra
Category: Handheld Mobile Computer
Model: MC3300ax
Part numbers: MC330X-GE3BDT-RW, MC330X-SJ3BDT-RW, MC330X-GE2BDT-RW, MC330X-GJ4BDT-RW, MC330X-GJ2BDT-RW, MC330X-GJ3BDT-RW +1 more
Also known as: Zebra MC3300ax handheld mobile computer 10.2 cm (4") 800 x 480 pixels Touchscreen 474 g Black

Specifications

45 specifications in 14 groups

Display

Specification	Value
Display diagonal	10.2 cm (4")
Display resolution	800 x 480 pixels
Touchscreen	Yes
Display glass type	Gorilla Glass

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	LPDDR4
Flash memory	32 GB
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Maximum memory card size	512 GB

Processor

Specification	Value
Processor frequency	2.2 GHz
Processor family	Snapdragon
Processor model	660
Processor manufacturer	Qualcomm
Number of cores	8
Built-in processor	Yes

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth	Yes
Bluetooth version	5.1
Bluetooth Low Energy (BLE)	Yes
Data network	Not supported
Near Field Communication (NFC)	Yes

GPS Performance

Specification	Value
GPS (satellite)	No

Audio

Specification	Value
Built-in microphone	Yes
Speakers	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	1

Performance

Specification	Value
Product colour	Black
Barcode reader	Yes
Drop proof	180 cm
Drop proof	Yes
International Protection (IP) code	IP64
Push-to-Talk (PTT)	Yes

Sensors

Specification	Value
Accelerometer	Yes

Software

Specification	Value
Operating system installed	Android
Operating system upgradeable	Yes

Power

Specification	Value
Battery voltage	3.6 V

Weight & dimensions

Specification	Value
Weight	474 g
Width	74.7 mm
Depth	34.5 mm
Height	202.6 mm

Operational conditions

Specification	Value
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-40 - 70 °C

Battery

Specification	Value
Battery capacity	7000 mAh
Battery technology	Lithium-Ion (Li-Ion)
