FX7400-42310A30-US handheld mobile computer
820 g White
Model FX7400-42310A30-US
31 specifications
- Memory0.064 GB
- Connectivity2 x In, 2 x Out
- OSWindows CE 5.0
- Weight820 g
- ColourWhite
- BluetoothNo
Overview
- Memory
- 0.064 GB
- Connectivity
- 2 x In, 2 x Out
- OS
- Windows CE 5.0
- Weight
- 820 g
- Colour
- White
- Bluetooth
- No
- Brand
- Zebra
- Category
- Handheld Mobile Computer
- Model
- FX7400-42310A30-US
- Part number
- FX7400-42310A30-US
- Also known as
- Zebra FX7400-42310A30-US handheld mobile computer 820 g White
Specifications
31 specifications in 11 groups
Memory
| Specification | Value |
|---|---|
| Internal memory | 0.064 GB |
| Internal memory type | RAM |
| Flash memory | 0.064 GB |
Network
| Specification | Value |
|---|---|
| Bluetooth | No |
| Data network | Not supported |
| Networking features | Fast Ethernet |
| Operating frequency | 902 - 928 MHz |
GPS Performance
| Specification | Value |
|---|---|
| GPS (satellite) | No |
Camera
| Specification | Value |
|---|---|
| Built-in camera | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Interface | 2 x In, 2 x Out |
Performance
| Specification | Value |
|---|---|
| Product colour | White |
| Barcode reader | No |
| RFID reader | Yes |
| Phone function | No |
| LED indicators | Power, Status |
| Power over Ethernet (PoE) | Yes |
| Certification | UL, IEC, EN, FCC, RSS, ICES, ROHS, WEEE |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows CE 5.0 |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 24 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 820 g |
| Dimensions (WxDxH) | 149.9 x 43.2 x 195.6 mm |
| Width | 149.9 mm |
| Depth | 43.2 mm |
| Height | 195.6 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Relative humidity | 5 - 95% |
Technical details
| Specification | Value |
|---|---|
| Supported network protocols | XML, HTTP/HTTPS, SNMP, AirBEAM, DHCP, FTPS, SSH, FTP, Telnet, NTP, LLRP |
| Wall mountable | Yes |
