2-port USB 3.0 Peripheral Sharing Device
Model US234Part no. US234-ATEAN 672792006821
28 specifications
- Speed5 Gbit/s
- Weight258 g
- ColourBlack
- USB 2.0 ports quantity0
- Operating temperature (T-T)0 - 40 °C
- Width93 mm
Overview
- Speed
- 5 Gbit/s
- Weight
- 258 g
- Colour
- Black
- USB 2.0 ports quantity
- 0
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 93 mm
- Brand
- ATEN
- Category
- Computer Data Switch
- Model
- US234
- Part numbers
- US234-AT, US234
- EAN / UPC
- 672792006821, 4719264643781, 5057103120208
- Also known as
- ATEN 2-port USB 3.0 Peripheral Sharing Device
Specifications
28 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 2 |
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 5 Gbit/s |
| Remote control function | Yes |
| LED indicators | Yes |
| Power connector | Micro-USB Type-B |
| Product colour | Black |
| Housing material | Plastic |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 93 mm |
| Depth | 93.7 mm |
| Height | 26.8 mm |
| Weight | 258 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 163 mm |
| Package width | 70 mm |
| Package height | 195 mm |
| Package weight | 392 g |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case gross weight | 4.64 kg |
| Master (outer) case height | 182 mm |
| Master (outer) case length | 405 mm |
| Master (outer) case net weight | 2.58 kg |
| Master (outer) case width | 395 mm |
| Products per master (outer) case | 10 pc(s) |
