RESERATOR5 Z24 ARGB BLACK
Model RESERATOR5 Z24 ARGB BLACKEAN 8809213766107
35 specifications
- TypeAll-in-one liquid cooler
- ColourBlack
- Suitable locationProcessor
- Power consumption (typical)4.2 W
- Radiator width27.8 cm
Overview
- Type
- All-in-one liquid cooler
- Colour
- Black
- Suitable location
- Processor
- Power consumption (typical)
- 4.2 W
- Radiator width
- 27.8 cm
- Brand
- Zalman
- Category
- Computer Cooling System
- Model
- RESERATOR5 Z24 ARGB BLACK
- Part number
- RESERATOR5 Z24 ARGB BLACK
- EAN / UPC
- 8809213766107
- Also known as
- Zalman RESERATOR5 Z24 ARGB BLACK computer cooling system Processor All-in-one liquid cooler 12 cm
Specifications
35 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM4, Socket AM5 |
| Maximum air pressure | 1.43 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Fan noise level (max) | 28 dB |
| Fan bearing technology | Hydro bearing |
| Pump bearing technology | Ceramic bearing |
| Fan speed (max) | 1800 RPM |
| Fan speed (min) | 700 RPM |
| Pump motor speed (max) | 2500 RPM |
| Pump motor speed (min) | 1000 RPM |
| Fan's mean time to failure (MTTF) | 50000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Polypropylene carbonate (PPC), Polystyrene (PS) |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 4.2 W |
| Rated voltage | 12 V |
| Fan power consumption | 4.2 W |
| Pump power consumption | 4.2 W |
| Fan current | 0.35 A |
| Fan voltage | 12 V |
| Pump current | 0.35 mA |
| Pump voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Radiator width | 27.8 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Pump width | 8.2 cm |
| Pump depth | 8.2 cm |
| Pump height | 4 cm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Other features
| Specification | Value |
|---|---|
| Thermal grease | Yes |
