CNPS80G Rev.3
Model CNPS80G Rev.3Part no. CNPS80G REV.3EAN 8809213764608
23 specifications
- Noise28 dB
- TypeAir cooler
- Weight180 g
- ColourAluminium, Black
- Suitable locationProcessor
- Power consumption (typical)1.2 W
Overview
- Noise
- 28 dB
- Type
- Air cooler
- Weight
- 180 g
- Colour
- Aluminium, Black
- Suitable location
- Processor
- Power consumption (typical)
- 1.2 W
- Brand
- Zalman
- Category
- Computer Cooling System
- Model
- CNPS80G Rev.3
- Part number
- CNPS80G REV.3
- EAN / UPC
- 8809213764608
- Also known as
- Zalman CNPS80G Rev.3 Processor Air cooler 8.5 cm Aluminium, Black
Specifications
23 specifications in 4 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | Air cooler |
| Fan diameter | 8.5 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM3, Socket AM3+, Socket AM4, Socket AM5 |
| Rotational speed (min) | 900 RPM |
| Rotational speed (max) | 2500 RPM |
| Noise level (high speed) | 28 dB |
| Maximum airflow | 31.1 cfm |
| Airflow | 52.83 m³/h |
| Maximum air pressure | 1.51 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Fan's mean time to failure (MTTF) | 50000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Aluminium, Black |
| Material | Aluminium |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 1.2 W |
| Rated voltage | 12 V |
| Rated current | 0.1 A |
| Thermal Design Power (TDP) | 65 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 110 mm |
| Depth | 102 mm |
| Height | 50 mm |
| Weight | 180 g |
