CNPS10X OptimaII
Model CNPS10X OptimaIIPart no. CNPS10X OPTIMAIIEAN 8809213769146
29 specifications
- Noise18 dB
- TypeCooler
- Weight740 g
- ColourWhite
- Suitable locationProcessor
- Rated voltage12 V
Overview
- Noise
- 18 dB
- Type
- Cooler
- Weight
- 740 g
- Colour
- White
- Suitable location
- Processor
- Rated voltage
- 12 V
- Brand
- Zalman
- Category
- Computer Cooling System
- Model
- CNPS10X OptimaII
- Part numbers
- CNPS10X OPTIMAII, CNPS10X OPTIMAII BLACK
- EAN / UPC
- 8809213769146, 8809213769511
- Also known as
- Zalman CNPS10X OptimaII Processor Cooler 12 cm White
Specifications
29 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | Cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM3, Socket AM3+, Socket AM4, Socket FM2, Socket FM2+ |
| Rotational speed (min) | 800 RPM |
| Rotational speed (max) | 1500 RPM |
| Noise level (low speed) | 18 dB |
| Noise level (high speed) | 27 dB |
| Maximum airflow | 61.52 cfm |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Hydraulic |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Material | Aluminium, Copper, Plastic |
| Number of heat pipes | 4 |
| Illumination LED | Yes |
| Illumination colour | Multi |
| Fan connector | 3-pin + 4-pin |
| Certification | CE |
Power
| Specification | Value |
|---|---|
| Rated voltage | 12 V |
| Thermal Design Power (TDP) | 150 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 132 mm |
| Depth | 85 mm |
| Height | 160 mm |
| Weight | 740 g |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
| Screws included | Yes |
Other features
| Specification | Value |
|---|---|
| Thermal grease | Yes |
