120x25mm Computer Case Fan with PWM – Pulse Width Modulation Connector
Model FAN12025PWMEAN 966210825669
26 specifications
- Noise39 dB
- TypeFan
- Weight128 g
- ColourBlack
- Suitable locationComputer case
- Voltage12 V
Overview
- Noise
- 39 dB
- Type
- Fan
- Weight
- 128 g
- Colour
- Black
- Suitable location
- Computer case
- Voltage
- 12 V
- Brand
- StarTech.com
- Category
- Computer Cooling System
- Model
- FAN12025PWM
- Part number
- FAN12025PWM
- EAN / UPC
- 966210825669, 065030845335, 102930672545, 115971576192 +9 more
- Also known as
- StarTech.com 120x25mm Computer Case Fan with PWM – Pulse Width Modulation Connector
Specifications
26 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 12 cm |
| Noise level (high speed) | 39 dB |
| Mean time between failures (MTBF) | 40000 h |
| Operating temperature (T-T) | -10 - 70 °C |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Plastic |
Power
| Specification | Value |
|---|---|
| Voltage | 12 V |
| Rated current | 0.32 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 128 g |
| Package width | 145 mm |
| Package depth | 208 mm |
| Package height | 34 mm |
| Package weight | 188 g |
Other features
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 65% |
| Fan performance | 78.41 cfm |
| Connector(s) | 1 - Molex Fan (4 pin; PWM) |
| Dimensions (WxDxH) | 120 x 120 x 25 mm |
| Rotational speed | 220 RPM |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 528 mm |
| Master (outer) case length | 378 mm |
| Master (outer) case height | 324 mm |
| Products per master (outer) case | 60 pc(s) |
