MAGCORELIQUID P240
Model MAGCORELIQUID P240Part no. MAG CORELIQUID P240EAN 4719072851460
40 specifications
- Noise14.3 dB
- TypeAll-in-one liquid cooler
- ColourBlack
- Suitable locationProcessor
- Fan power consumption1.8 W
- Radiator width27.6 cm
Overview
- Noise
- 14.3 dB
- Type
- All-in-one liquid cooler
- Colour
- Black
- Suitable location
- Processor
- Fan power consumption
- 1.8 W
- Radiator width
- 27.6 cm
- Brand
- MSI
- Category
- Computer Cooling System
- Model
- MAGCORELIQUID P240
- Part number
- MAG CORELIQUID P240
- EAN / UPC
- 4719072851460
- Also known as
- MSI MAG CORELIQUID P240 Liquid CPU Cooler '240mm Radiator, 2x 120mm PWM Fan, Compatible with Intel and AMD Platforms, Latest LGA 1700 ready'
Specifications
40 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2, Socket FM2+ |
| Rotational speed (min) | 500 RPM |
| Rotational speed (max) | 2000 RPM |
| Noise level (low speed) | 14.3 dB |
| Noise level (high speed) | 34.3 dB |
| Maximum airflow | 78.73 cfm |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Dual ball bearing |
| Fan noise level (min) | 14.3 dB |
| Fan noise level (max) | 34.3 dB |
| Fan bearing technology | Double ball bearing |
| Fan static pressure | 2.39 mmH2O |
| Pump motor speed | 4200 RPM |
| Pump's mean time to failure (MTTF) | 100000 h |
| Fan's mean time to failure (MTTF) | 70000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Radiator material | Aluminum |
| Number of fans | 2 fan(s) |
| Illumination LED | No |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Fan power consumption | 1.8 W |
| Pump power consumption | 4.08 W |
| Fan current | 0.15 A |
| Fan voltage | 12 V |
| Pump current | 0.34 mA |
| Pump voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Radiator width | 27.6 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 40 cm |
| Waterblock width | 7.05 cm |
| Waterblock depth | 7.05 cm |
| Waterblock height | 5.2 cm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Fan 2 dimensions (W x D x H) | 120 x 120 x 25 mm |
Other features
| Specification | Value |
|---|---|
| Noise level | 14.3 dB |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
