MAG CoreLiquid C240
Model MAG CoreLiquid C240Part no. 824142258996
41 specifications
- TypeAll-in-one liquid cooler
- ColourBlack
- Suitable locationProcessor
- Fan power consumption1.8 W
- Radiator width27.6 cm
Overview
- Type
- All-in-one liquid cooler
- Colour
- Black
- Suitable location
- Processor
- Fan power consumption
- 1.8 W
- Radiator width
- 27.6 cm
- Brand
- MSI
- Category
- Computer Cooling System
- Model
- MAG CoreLiquid C240
- Part number
- 824142258996
- Also known as
- MSI MAG CoreLiquid C240 Processor All-in-one liquid cooler 12 cm Black 1 pc(s)
Specifications
41 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM4, Socket AM5, Socket FM1, Socket FM2+ |
| Maximum airflow | 78.73 cfm |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Dual ball bearing |
| Fan noise level (min) | 14.3 dB |
| Fan noise level (max) | 34.3 dB |
| Pump noise level | 18 dB |
| Quantity per pack | 1 pc(s) |
| Fan speed (max) | 2000 RPM |
| Fan speed (min) | 500 RPM |
| Fan static pressure | 2.39 mmH2O |
| Pump motor speed | 4200 RPM |
| Pump's mean time to failure (MTTF) | 100000 h |
| Fan's mean time to failure (MTTF) | 70000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Aluminium |
| Radiator material | Aluminum |
| Number of fans | 2 fan(s) |
| Illumination LED | Yes |
| Illumination colour | Multi |
| Fan connector | 4-pin + 4-pin |
Power
| Specification | Value |
|---|---|
| Fan power consumption | 1.8 W |
| Pump power consumption | 4.08 W |
| Fan current | 0.15 A |
| Fan voltage | 12 V |
| Pump current | 0.34 mA |
| Pump voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Radiator width | 27.6 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 40 cm |
| Waterblock width | 7.05 cm |
| Waterblock depth | 7.05 cm |
| Waterblock height | 5.2 cm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Cable length | 0.55 m |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Fan |
Other features
| Specification | Value |
|---|---|
| Air pressure | 2.39 mmH2O |
