ML-VISIONII360 Processor All-in-one liquid cooler
12 cm Black 1 pc(s)
Model ML-VISIONII360Part no. MLVISIONII360EAN 8435693112518
52 specifications
- Display7.11 cm (2.8")
- Resolution320 x 240 pixels
- TypeAll-in-one liquid cooler
- Weight1.17 kg
- ColourBlack
- Suitable locationProcessor
Overview
- Display
- 7.11 cm (2.8")
- Resolution
- 320 x 240 pixels
- Type
- All-in-one liquid cooler
- Weight
- 1.17 kg
- Colour
- Black
- Suitable location
- Processor
- Brand
- Mars Gaming
- Category
- Computer Cooling System
- Model
- ML-VISIONII360
- Part numbers
- MLVISIONII360, MLVISIONII360W
- EAN / UPC
- 8435693112518, 8435693112532
- Also known as
- Mars Gaming ML-VISIONII360 Processor All-in-one liquid cooler 12 cm Black 1 pc(s)
Specifications
52 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1851, LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM5, Socket AM4 |
| Minimum airflow (imperial) | 27.2 cfm |
| Maximum airflow | 76.6 cfm |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Hydraulic |
| Fan noise level (min) | 9 dB |
| Fan noise level (max) | 26 dB |
| Pump noise level | 15 dB |
| Pump connector | 3-pin |
| Quantity per pack | 1 pc(s) |
| Fan speed (max) | 2300 RPM |
| Fan speed (min) | 800 RPM |
| Pump motor speed | 2800 RPM |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Number of fans | 3 fan(s) |
| Fins material | Aluminium |
| Illumination LED | Yes |
| Illumination colour | Multi |
| LED connector type | 3-pin |
| Fan connector | 4-pin |
| Display diagonal | 7.11 cm (2.8") |
| Display type | IPS |
| Display resolution | 320 x 240 pixels |
Power
| Specification | Value |
|---|---|
| Voltage | 12 V |
| Fan current | 0.15 A |
| Fan voltage | 12 V |
| LED voltage | 5 V |
| Rated current | 0.25 A |
| Thermal Design Power (TDP) | 600 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 360 mm |
| Radiator width | 39.5 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.8 cm |
| Tube length | 40 cm |
| Pump width | 7 cm |
| Pump depth | 8.4 cm |
| Pump height | 4.8 cm |
| Weight | 1.17 kg |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Package width | 455 mm |
| Package depth | 203 mm |
| Package height | 142 mm |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
| Mounting kit | Yes |
| Screws included | Yes |
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Thermal grease | Yes |
