MCPU-X3 Processor Air cooler
9 cm Black 1 pc(s)
Model MCPU-X3Part no. MCPUX3EAN 8435693113355
42 specifications
- TypeAir cooler
- Weight248 g
- ColourBlack
- Suitable locationProcessor
- Fan power consumption2.4 W
- Width93 mm
Overview
- Type
- Air cooler
- Weight
- 248 g
- Colour
- Black
- Suitable location
- Processor
- Fan power consumption
- 2.4 W
- Width
- 93 mm
- Brand
- Mars Gaming
- Category
- Computer Cooling System
- Model
- MCPU-X3
- Part number
- MCPUX3
- EAN / UPC
- 8435693113355
- Also known as
- Mars Gaming MCPU-X3 Processor Air cooler 9 cm Black 1 pc(s)
Specifications
42 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | Air cooler |
| Fan diameter | 9 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 1851, Socket AM4, Socket AM5 |
| Minimum airflow (imperial) | 28 cfm |
| Maximum airflow | 67 cfm |
| Minimum air pressure | 0.8 mmH2O |
| Maximum air pressure | 1.25 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Hydraulic |
| Fan noise level (min) | 9 dB |
| Fan noise level (max) | 28 dB |
| Quantity per pack | 1 pc(s) |
| Fan speed (max) | 2600 RPM |
| Fan speed (min) | 800 RPM |
| Fan's mean time to failure (MTTF) | 60000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Number of fans | 1 fan(s) |
| Fins material | Aluminium |
| Number of heat pipes | 3 |
| Illumination LED | Yes |
| Illumination colour | Multi |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Fan power consumption | 2.4 W |
| Fan current | 0.2 A |
| Fan voltage | 12 V |
| LED voltage | 5 V |
| Thermal Design Power (TDP) | 190 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 93 mm |
| Depth | 64 mm |
| Height | 132 mm |
| Weight | 248 g |
| Fan dimensions (W x D x H) | 90 x 25 x 90 mm |
| Package width | 145 mm |
| Package depth | 105 mm |
| Package height | 117 mm |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Anti-vibration system | Yes |
| Thermal grease | Yes |
