MCPU-LCDPRO Processor Air cooler
12 cm Black 1 pc(s)
Model MCPU-LCDPROPart no. MCPULCDPROEAN 8435693112860
45 specifications
- TypeAir cooler
- Weight977 g
- ColourBlack
- Suitable locationProcessor
- Fan power consumption6 W
- Width120 mm
Overview
- Type
- Air cooler
- Weight
- 977 g
- Colour
- Black
- Suitable location
- Processor
- Fan power consumption
- 6 W
- Width
- 120 mm
- Brand
- Mars Gaming
- Category
- Computer Cooling System
- Model
- MCPU-LCDPRO
- Part number
- MCPULCDPRO
- EAN / UPC
- 8435693112860
- Also known as
- Mars Gaming MCPU-LCDPRO Processor Air cooler 12 cm Black 1 pc(s)
Specifications
45 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | Air cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 1851, Socket AM4, Socket AM5 |
| Minimum airflow (imperial) | 30 cfm |
| Maximum airflow | 72 cfm |
| Minimum air pressure | 0.85 mmH2O |
| Maximum air pressure | 1.4 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Hydraulic |
| Fan noise level (min) | 9 dB |
| Fan noise level (max) | 26 dB |
| Quantity per pack | 1 pc(s) |
| Fan speed (max) | 2300 RPM |
| Fan speed (min) | 800 RPM |
| Fan's mean time to failure (MTTF) | 60000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Radiator material | Aluminum |
| Base plate material | Copper |
| Number of fans | 2 fan(s) |
| Fins material | Aluminium |
| Number of heat pipes | 8 |
| Illumination LED | Yes |
| Illumination colour | Multi |
| LED connector type | 3-pin |
| Fan connector | 4-pin |
| Display type | LCD |
Power
| Specification | Value |
|---|---|
| Fan power consumption | 6 W |
| Fan current | 0.5 A |
| Fan voltage | 12 V |
| LED voltage | 5 V |
| Thermal Design Power (TDP) | 380 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 118 mm |
| Height | 158 mm |
| Weight | 977 g |
| Fan dimensions (W x D x H) | 120 x 25 x 120 mm |
| Package width | 196 mm |
| Package depth | 160 mm |
| Package height | 180 mm |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Anti-vibration system | Yes |
| Thermal grease | Yes |
| Built-in display | Yes |
