EVOLIQ 240
Model EVOLIQ 240Part no. ITLCEVOR240EAN 8056157881643
29 specifications
- TypeAll-in-one liquid cooler
- ColourBlack
- Suitable locationProcessor
- Pump current46 mA
- Radiator width27.4 cm
Overview
- Type
- All-in-one liquid cooler
- Colour
- Black
- Suitable location
- Processor
- Pump current
- 46 mA
- Radiator width
- 27.4 cm
- Brand
- itek
- Category
- Computer Cooling System
- Model
- EVOLIQ 240
- Part number
- ITLCEVOR240
- EAN / UPC
- 8056157881643
- Also known as
- itek EVOLIQ 240 Processor All-in-one liquid cooler Black
Specifications
29 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | All-in-one liquid cooler |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 1700, LGA 1851, LGA 2011 (Socket R), LGA 2066, LGA 775 (Socket T), Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket AM5, Socket FM1, Socket FM2, Socket FM2+, Socket TR4 |
| Maximum airflow | 65.4 cfm |
| Pulse-width modulation (PWM) support | Yes |
| Fan noise level (min) | 8 dB |
| Fan noise level (max) | 30.8 dB |
| Pump noise level | 16 dB |
| Fan bearing technology | Hydraulic bearing |
| Fan speed (max) | 1600 RPM |
| Fan speed (min) | 800 RPM |
| Fan static pressure | 2.36 mmH2O |
| Pump motor speed (min) | 2600 RPM |
| Pump's mean time to failure (MTTF) | 50000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Radiator material | Aluminium |
| Number of fans | 2 fan(s) |
| Illumination LED | Yes |
Power
| Specification | Value |
|---|---|
| Pump current | 46 mA |
| Thermal Design Power (TDP) | 250 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Radiator width | 27.4 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Tube length | 40 cm |
| Waterblock width | 7 cm |
| Waterblock depth | 8 cm |
| Waterblock height | 5.43 cm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Other features
| Specification | Value |
|---|---|
| Tube material | PTFE |
