Cyclone II LED Blue
Model Cyclone II LED BluePart no. DG-VCPU-CY2-LBEAN 8436556143359
32 specifications
- Noise18 dB
- TypeCooler
- Weight570 g
- ColourBlack
- Suitable locationProcessor
- Power consumption (typical)2.4 W
Overview
- Noise
- 18 dB
- Type
- Cooler
- Weight
- 570 g
- Colour
- Black
- Suitable location
- Processor
- Power consumption (typical)
- 2.4 W
- Brand
- Deep Gaming
- Category
- Computer Cooling System
- Model
- Cyclone II LED Blue
- Part number
- DG-VCPU-CY2-LB
- EAN / UPC
- 8436556143359
- Also known as
- Deep Gaming Cyclone II LED Blue Processor Cooler 12 cm Black 1 pc(s)
Specifications
32 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | Cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 2011 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4 |
| Rotational speed (min) | 700 RPM |
| Rotational speed (max) | 1800 RPM |
| Noise level (low speed) | 18 dB |
| Noise level (high speed) | 35.2 dB |
| Maximum airflow | 74.5 cfm |
| Maximum air pressure | 2.15 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Hydraulic |
| Quantity per pack | 1 pc(s) |
| Mean time between failures (MTBF) | 30000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Number of fan blades | 11 |
| Fins material | Aluminium |
| Number of heat pipes | 4 |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.4 W |
| Rated voltage | 12 V |
| Rated current | 0.2 A |
| Thermal Design Power (TDP) | 130 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 73 mm |
| Height | 156 mm |
| Weight | 570 g |
| Fan dimensions (W x D x H) | 120 x 25 x 120 mm |
| Fan weight | 130 g |
| Heat pipes diameter | 6 mm |
Other features
| Specification | Value |
|---|---|
| Heatsink dimensions (W x D x H) | 120 x 48 x 156 mm |
