be quiet! SHADOW WINGS SW1 92mm PWM
Model SHADOW WINGS SW1 92mm PWMPart no. BL025EAN 4014169375721
25 specifications
- Noise17.8 dB
- TypeFan
- Weight170 g
- ColourBlack
- Suitable locationComputer case
- Power consumption (typical)2.04 W
Overview
- Noise
- 17.8 dB
- Type
- Fan
- Weight
- 170 g
- Colour
- Black
- Suitable location
- Computer case
- Power consumption (typical)
- 2.04 W
- Brand
- be quiet!
- Category
- Computer Cooling System
- Model
- SHADOW WINGS SW1 92mm PWM
- Part number
- BL025
- EAN / UPC
- 4014169375721, 4260052182659
- Also known as
- be quiet! SHADOW WINGS SW1 92mm PWM Computer case Fan 9.2 cm Black
Specifications
25 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 9.2 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (max) | 1800 RPM |
| Noise level (high speed) | 17.8 dB |
| Maximum airflow | 32.6 cfm |
| Airflow | 54.4 m³/h |
| Maximum air pressure | 1.98 mmH2O |
| Mean time between failures (MTBF) | 200000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Certification | CE, WEEE, RU, Tüv |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.04 W |
| Voltage | 5 - 12 V |
| Rated current | 0.17 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 92 mm |
| Depth | 25 mm |
| Height | 92 mm |
| Weight | 170 g |
| Cable length | 0.45 m |
Technical details
| Specification | Value |
|---|---|
| Bearing technology | Rifle |
| Compliance certificates | RoHS |
Other features
| Specification | Value |
|---|---|
| Compatible chipsets | Not supported |
| Connector(s) | 4p |
