be quiet! SHADOW WINGS SW1 120mm PWM
Model SHADOW WINGS SW1 120mm PWMPart no. BL026EAN 5054629293188
25 specifications
- Noise18.9 dB
- TypeFan
- Weight220 g
- ColourBlack
- Suitable locationComputer case
- Power consumption (typical)2.4 W
Overview
- Noise
- 18.9 dB
- Type
- Fan
- Weight
- 220 g
- Colour
- Black
- Suitable location
- Computer case
- Power consumption (typical)
- 2.4 W
- Brand
- be quiet!
- Category
- Computer Cooling System
- Model
- SHADOW WINGS SW1 120mm PWM
- Part number
- BL026
- EAN / UPC
- 5054629293188, 3548389100395, 4014169375738, 4260052182666 +3 more
- Also known as
- be quiet! SHADOW WINGS SW1 120mm PWM Computer case Fan 12 cm Black
Specifications
25 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (max) | 1500 RPM |
| Noise level (high speed) | 18.9 dB |
| Maximum airflow | 50.5 cfm |
| Airflow | 85 m³/h |
| Maximum air pressure | 1.63 mmH2O |
| Mean time between failures (MTBF) | 200000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Certification | CE, WEEE, RU, Tüv |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.4 W |
| Voltage | 5 - 12 V |
| Rated current | 0.2 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 25 mm |
| Height | 120 mm |
| Weight | 220 g |
| Cable length | 0.45 m |
Technical details
| Specification | Value |
|---|---|
| Bearing technology | Rifle |
| Compliance certificates | RoHS |
Other features
| Specification | Value |
|---|---|
| Compatible chipsets | Not supported |
| Connector(s) | 4p |
