PURE LOOP 280mm
Model PURE LOOP 280mmPart no. BW007EAN 4260052187906
45 specifications
- TypeAll-in-one liquid cooler
- Weight1.22 kg
- ColourBlack
- Suitable locationProcessor
- Fan power consumption6 W
- Radiator width14 cm
Overview
- Type
- All-in-one liquid cooler
- Weight
- 1.22 kg
- Colour
- Black
- Suitable location
- Processor
- Fan power consumption
- 6 W
- Radiator width
- 14 cm
- Brand
- be quiet!
- Category
- Computer Cooling System
- Model
- PURE LOOP 280mm
- Part number
- BW007
- EAN / UPC
- 4260052187906
- Also known as
- be quiet! Pure Loop 280mm All In One CPU Water Cooling, 2 X 140mm PWM Fan, For Intel Socket: 1200 / 2066 / 115X / 2011(-3) square ILM; For AMD Socket: AMD: AM4
Specifications
45 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | All-in-one liquid cooler |
| Fan diameter | 14 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 2011 (Socket R), LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), LGA 1155 (Socket H2), LGA 2066, Socket AM4, LGA 1200 (Socket H5), Socket AM5, LGA 1700 |
| Pulse-width modulation (PWM) support | Yes |
| Fan noise level (min) | 22.5 dB |
| Fan noise level (max) | 38.1 dB |
| Fan bearing technology | Rifle bearing |
| Pump connector | 3-pin |
| Quantity per pack | 1 pc(s) |
| Fan speed (max) | 1600 RPM |
| Pump motor speed | 5500 RPM |
| Fan's mean time to failure (MTTF) | 80000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Radiator material | Aluminium |
| Base plate material | Copper |
| Number of fans | 2 fan(s) |
| Illumination LED | Yes |
| Illumination colour | White |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Fan power consumption | 6 W |
| Fan current | 0.5 A |
| Fan voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Radiator width | 14 cm |
| Radiator depth | 5.2 cm |
| Radiator height | 31.7 cm |
| Tube length | 40 cm |
| Weight | 1.22 kg |
| Fan dimensions (W x D x H) | 317 x 140 x 52 mm |
| Fan thickness | 2.5 cm |
| Package width | 152 mm |
| Package depth | 365 mm |
| Package height | 205 mm |
| Package weight | 2.14 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Pulse Width Modulation (PWM) Y-cable, RGB splitter cable |
| Manual | Yes |
| CPU bracket(s) | Yes |
Other features
| Specification | Value |
|---|---|
| Thermal grease | Yes |
| Country of origin | Germany |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
| Products per shipping (inner) case | 6 pc(s) |
| Shipping (inner) case width | 29.6 cm |
| Shipping (inner) case length | 65.8 cm |
| Shipping (inner) case height | 50.8 cm |
| Shipping (inner) case gross weight | 14.9 kg |
