P8 - Pressure-optimised
80 mm Fan
Model P8Part no. ACFAN00153AEAN 872767009950
34 specifications
- Noise0.3 sone
- TypeFan
- Weight81 g
- ColourBlack
- Suitable locationComputer case
- Voltage12 V
Overview
- Noise
- 0.3 sone
- Type
- Fan
- Weight
- 81 g
- Colour
- Black
- Suitable location
- Computer case
- Voltage
- 12 V
- Brand
- ARCTIC
- Category
- Computer Cooling System
- Model
- P8
- Part numbers
- ACFAN00153A, ACFAN00147A
- EAN / UPC
- 872767009950, 872767009882, 4895213701990, 4895213702065
- Also known as
- ARCTIC P8 - Pressure-optimised 80 mm Fan
Specifications
34 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 8 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (max) | 3000 RPM |
| Noise level | 0.3 sone |
| Maximum airflow | 23.4 cfm |
| Airflow | 39.76 m³/h |
| Maximum air pressure | 1.9 mmH2O |
| Bearing type | Fluid Dynamic Bearing (FDB) |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Number of fan blades | 5 |
| Illumination LED | No |
| Fan connector | 3-pin |
| Display type | Not applicable |
Power
| Specification | Value |
|---|---|
| Voltage | 12 V |
| Rated current | 0.14 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 25 mm |
| Height | 80 mm |
| Weight | 81 g |
| Cable length | 0.4 m |
| Package width | 82.5 mm |
| Package depth | 26 mm |
| Package height | 82.5 mm |
| Package weight | 99 g |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
| Screws included | Yes |
| Number of screws | 4 |
Other features
| Specification | Value |
|---|---|
| Mounting hole pattern (W x D) | 71.5 x 71.5 mm |
| Country of origin | China |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
