P14 Max (White)
Model P14 Max (White)Part no. ACFAN00304AEAN 4895213704816
32 specifications
- TypeFan
- Weight254 g
- ColourWhite
- Suitable locationComputer case
- Voltage12 V
- Width140 mm
Overview
- Type
- Fan
- Weight
- 254 g
- Colour
- White
- Suitable location
- Computer case
- Voltage
- 12 V
- Width
- 140 mm
- Brand
- ARCTIC
- Category
- Computer Cooling System
- Model
- P14 Max (White)
- Part number
- ACFAN00304A
- EAN / UPC
- 4895213704816
- Also known as
- ARCTIC P14 Max (White) - 140 mm High-Speed PWM Fan
Specifications
32 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 14 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (min) | 400 RPM |
| Rotational speed (max) | 2800 RPM |
| Maximum airflow | 95 cfm |
| Airflow | 161.4 m³/h |
| Maximum air pressure | 4.18 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Operating temperature (T-T) | 0 - 40 °C |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Number of fans | 1 fan(s) |
| Number of fan blades | 5 |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Voltage | 12 V |
| Starting voltage | 3.9 V |
| Rated current | 0.35 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 140 mm |
| Height | 27 mm |
| Weight | 254 g |
| Cable length | 0.4 m |
| Package width | 167 mm |
| Package depth | 167 mm |
| Package height | 34 mm |
| Package weight | 303 g |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
| Screws included | Yes |
| Number of screws | 4 |
