ARCTIC P12 PWM
Model P12 PWMPart no. ACFAN00171AEAN 4895213702270
36 specifications
- Noise24.5 dB
- TypeFan
- Weight139 g
- ColourBlack
- Suitable locationComputer case
- Power consumption (typical)0.96 W
Overview
- Noise
- 24.5 dB
- Type
- Fan
- Weight
- 139 g
- Colour
- Black
- Suitable location
- Computer case
- Power consumption (typical)
- 0.96 W
- Brand
- ARCTIC
- Category
- Computer Cooling System
- Model
- P12 PWM
- Part numbers
- ACFAN00171A, ACFAN00119A, ACFAN00131A, ACFAN00133A
- EAN / UPC
- 4895213702270, 872767009332, 4895213701389, 872767009356 +5 more
- Also known as
- ARCTIC P12 PWM (Black/Black) Pressure-optimised 120 mm Fan with PWM
Specifications
36 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (min) | 200 RPM |
| Rotational speed (max) | 1800 RPM |
| Noise level (high speed) | 24.5 dB |
| Noise level | 0.3 sone |
| Maximum airflow | 56.3 cfm |
| Airflow | 95.65 m³/h |
| Maximum air pressure | 2.2 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Fluid Dynamic Bearing (FDB) |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Number of fan blades | 5 |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 0.96 W |
| Voltage | 12 V |
| Starting voltage | 3.9 V |
| Rated current | 0.08 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 120 mm |
| Height | 25 mm |
| Weight | 139 g |
| Cable length | 0.4 m |
| Package width | 123 mm |
| Package depth | 123 mm |
| Package height | 27 mm |
| Package weight | 170 g |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
| Screws included | Yes |
| Number of screws | 4 |
Other features
| Specification | Value |
|---|---|
| Country of origin | China |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
