ARCTIC F9 PWM PST
Model F9 PWM PSTPart no. ACFAN00247AEAN 4895213703352
31 specifications
- Noise0.4 sone
- TypeFan
- Weight84 g
- ColourBlack, White
- Suitable locationComputer case
- Voltage12 V
Overview
- Noise
- 0.4 sone
- Type
- Fan
- Weight
- 84 g
- Colour
- Black, White
- Suitable location
- Computer case
- Voltage
- 12 V
- Brand
- ARCTIC
- Category
- Computer Cooling System
- Model
- F9 PWM PST
- Part numbers
- ACFAN00247A, AFACO-090P0-GBA01, ACFAN00214A
- EAN / UPC
- 4895213703352, 872767002647, 3609740136863, 4895213700023 +10 more
- Also known as
- ARCTIC F9 PWM PST 4-Pin PWM fan with standard case
Specifications
31 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 9.2 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (min) | 550 RPM |
| Rotational speed (max) | 2000 RPM |
| Noise level | 0.4 sone |
| Maximum airflow | 43 cfm |
| Airflow | 73.1 m³/h |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Fluid bearing |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Material | Plastic |
| Number of fans | 1 fan(s) |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Voltage | 12 V |
| Rated current | 0.16 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 92 mm |
| Depth | 25 mm |
| Height | 92 mm |
| Weight | 84 g |
| Cable length | 0.4 m |
| Package width | 96 mm |
| Package depth | 27 mm |
| Package height | 96 mm |
| Package weight | 107 g |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging content
| Specification | Value |
|---|---|
| Screws included | Yes |
| Number of screws | 4 |
Other features
| Specification | Value |
|---|---|
| Mounting hole pattern (W x D) | 82.5 x 82.5 mm |
