ARCTIC F8 PWM
Model F8 PWMPart no. ACFAN00207AEAN 4895213702850
28 specifications
- Noise0.3 sone
- TypeFan
- Weight71 g
- ColourBlack, White
- Suitable locationComputer case
- Voltage12 V
Overview
- Noise
- 0.3 sone
- Type
- Fan
- Weight
- 71 g
- Colour
- Black, White
- Suitable location
- Computer case
- Voltage
- 12 V
- Brand
- ARCTIC
- Category
- Computer Cooling System
- Model
- F8 PWM
- Part numbers
- ACFAN00207A, AFACO-080P2-GBA01
- EAN / UPC
- 4895213702850, 013201158661, 180993241014, 872767006706 +10 more
- Also known as
- ARCTIC F8 PWM - Pin PWM fan with standard case
Specifications
28 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 8 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (min) | 300 RPM |
| Rotational speed (max) | 2000 RPM |
| Noise level | 0.3 sone |
| Maximum airflow | 31 cfm |
| Airflow | 52.7 m³/h |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Fluid Dynamic Bearing (FDB) |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Number of fans | 1 fan(s) |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Voltage | 12 V |
| Rated current | 0.09 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 25 mm |
| Height | 80 mm |
| Weight | 71 g |
| Package width | 82.5 mm |
| Package depth | 26 mm |
| Package height | 82.5 mm |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
| Screws included | Yes |
| Number of screws | 4 |
Other features
| Specification | Value |
|---|---|
| Mounting hole pattern (W x D) | 71.5 x 71.5 mm |
