ARCTIC F14 PWM
Model F14 PWMPart no. ACFAN00218AEAN 4895213703017
30 specifications
- Noise24.5 dB
- TypeFan
- Weight180 g
- ColourBlack, White
- Suitable locationComputer case
- Voltage12 V
Overview
- Noise
- 24.5 dB
- Type
- Fan
- Weight
- 180 g
- Colour
- Black, White
- Suitable location
- Computer case
- Voltage
- 12 V
- Brand
- ARCTIC
- Category
- Computer Cooling System
- Model
- F14 PWM
- Part numbers
- ACFAN00218A, ACFAN00078A
- EAN / UPC
- 4895213703017, 804066538824, 872767008526, 4895213700979 +1 more
- Also known as
- ARCTIC F14 PWM 4-Pin PWM fan with standard case
Specifications
30 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 14 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Rotational speed (max) | 1350 RPM |
| Noise level (high speed) | 24.5 dB |
| Noise level | 0.3 sone |
| Maximum airflow | 74 cfm |
| Airflow | 126 m³/h |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Fluid Dynamic Bearing (FDB) |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Number of fans | 1 fan(s) |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Voltage | 12 V |
| Starting voltage | 6 V |
| Rated current | 0.11 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 27 mm |
| Height | 140 mm |
| Weight | 180 g |
| Cable length | 0.4 m |
| Package width | 143 mm |
| Package depth | 29 mm |
| Package height | 143 mm |
| Package weight | 215 g |
Packaging content
| Specification | Value |
|---|---|
| Screws included | Yes |
| Number of screws | 4 |
Other features
| Specification | Value |
|---|---|
| Country of origin | China |
