Mirage L120
Model Mirage L120Part no. MIRAGEL120EAN 4710562755985
33 specifications
- Noise26.8 dB
- TypeAll-in-one liquid cooler
- ColourBlack
- Suitable locationProcessor
- Fan power consumption3.36 W
- Radiator width15.4 cm
Overview
- Noise
- 26.8 dB
- Type
- All-in-one liquid cooler
- Colour
- Black
- Suitable location
- Processor
- Fan power consumption
- 3.36 W
- Radiator width
- 15.4 cm
- Brand
- Aerocool
- Category
- Computer Cooling System
- Model
- Mirage L120
- Part numbers
- MIRAGEL120, MIRAGEL120W
- EAN / UPC
- 4710562755985, 4710562759143
- Also known as
- Aerocool MIRAGEL120 CPU Liquid Cooling 12cm ARGB Fan TDP 200W Black
Specifications
33 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | All-in-one liquid cooler |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 2011 (Socket R), LGA 2066, LGA 775 (Socket T), Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM2, Socket FM2+ |
| Maximum airflow | 72.2 cfm |
| Maximum air pressure | 1.62 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Pump noise level | 20.2 dB |
| Fan bearing technology | Hydraulic bearing |
| Quantity per pack | 1 pc(s) |
| Fan speed (max) | 1800 RPM |
| Fan speed (min) | 600 RPM |
| Pump motor speed | 2300 RPM |
| Pump's mean time to failure (MTTF) | 80000 h |
| Fan's mean time to failure (MTTF) | 60000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Cooper |
| Radiator material | Aluminum |
| Illumination LED | Yes |
| Illumination colour | Multi |
| Fan connector | 4-pin |
| Water block material | Copper |
Power
| Specification | Value |
|---|---|
| Fan power consumption | 3.36 W |
| Pump power consumption | 2.64 W |
| Fan current | 0.28 A |
| Fan voltage | 12 V |
| Pump voltage | 12 V |
| Thermal Design Power (TDP) | 200 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Radiator width | 15.4 cm |
| Radiator depth | 12 cm |
| Radiator height | 2.7 cm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Other features
| Specification | Value |
|---|---|
| Noise level | 26.8 dB |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
