Cylon 4
Model Cylon 4Part no. CYLON4EAN 4718009159600
31 specifications
- Noise14 dB
- TypeCooler
- ColourBlack
- Suitable locationProcessor
- Power consumption (typical)7.2 W
- Width126.5 mm
Overview
- Noise
- 14 dB
- Type
- Cooler
- Colour
- Black
- Suitable location
- Processor
- Power consumption (typical)
- 7.2 W
- Width
- 126.5 mm
- Brand
- Aerocool
- Category
- Computer Cooling System
- Model
- Cylon 4
- Part number
- CYLON4
- EAN / UPC
- 4718009159600
- Also known as
- Aerocool Cylon 4 Processor Cooler 12 cm Black
Specifications
31 specifications in 4 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | Cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 2011 (Socket R), LGA 2066, LGA 775 (Socket T), Socket AM1, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4 |
| Rotational speed (min) | 800 RPM |
| Rotational speed (max) | 1800 RPM |
| Noise level (low speed) | 14 dB |
| Noise level (high speed) | 26 dB |
| Minimum airflow (imperial) | 26.1 cfm |
| Maximum airflow | 52.5 cfm |
| Minimum air pressure | 0.72 mmH2O |
| Maximum air pressure | 1.21 mmH2O |
| Bearing type | Hydraulic |
| Mean time between failures (MTBF) | 60000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Aluminium |
| Number of fans | 1 fan(s) |
| Number of heat pipes | 4 |
| Illumination LED | Yes |
| Illumination colour | Blue, Green, Red |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 7.2 W |
| Rated voltage | 12 V |
| Starting voltage | 5 V |
| Rated current | 0.6 A |
| Thermal Design Power (TDP) | 145 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 126.5 mm |
| Depth | 76 mm |
| Height | 155 mm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Heat pipes diameter | 6 mm |
